Super stiff frameset with integrated cable routing, titanium
Integrated Titanium Alloy
Seat-Post Platest
The titanium alloy seat-post plates are bonded to the
frame. Two pair of oval holes on each plate allows for
millimeter-precision position adjustment of the seat.
Oversize Rear Frame
The design of the rear frame is a characterized by two
generously sized horizontal stays that can accommodate
tires up to 40 mm in width (700C diameter).
Soft Tail Rear Frame
The absence of seat stays to close the rear triangle isolates
the seat tube and minimizes the stresses transmitted from
the rear wheel. The tail of the frame with a reversed “T”
section act as a rear shock absorber, making the frame
even more comfortable.
Replaceable
Rear Derailleur Hanger
The right dropout includes the mount for the
replaceable rear derailleur hanger, with ingeniously
integrates the threaded nut of the thru-axle.
Oversize Rear Dropouts
The rear frame is design for solidity and strength. The
oversize rear dropouts accommodate a 12 mm diameter
thru-axle.
MAIN FRAME
Carbon fiber main frame with internal cable routing
Titanium front and rear seatpost plates with millimeter-
precision position adjustment
142 mm rear thru-axle with replaceable rear derailleur hanger
Flat mount disc brake clamp for 140 or 160 mm rear rotor
Rear tire clearance up to 40 mm (700C rear wheel)
Standard finish: glossy 3K carbon
FRONT FORK
Carbon fiber front fork with internal cable routing
1 1/8” – 1 1/2” steerer tube
100 x 12 mm Thru-axle
Flat Mount disc brake clamp
Front tire clearance up to 47 mm (700C front wheel)
Standard finish: matte UD carbon
AERO STEM
Carbon fiber stem with internal cable routing
Carbon top cover + Carbon aero top cover
Finish: glossy 3K carbon
SEAT
Carbon fiber
Adjustable seat height and angle with 4 spacers
Seat-pad available as option
Adjustable neck rest available as option
Finish: glossy 3K carbon
FRONT BOOM
Carbon fiber boom with internal cable routing
Adjustable length (max 578 mm) with cutting mask
PressFit Road BB shell
Frame-Boom pairing with 6-4 screws
Standard finish: glossy 3K carbon
HANDLEBAR
Carbon fiber handlebar with internal cable routing
Adjustable length 300 mm
Width 440 mm
Angle 20°
Diameter 22.2 mm ready for bar-end shifter
Finish: glossy 3K carbon
HEADSET
Token A-Box internal cable routing headset
1 1/2″ steel sealed bearings
Composite compression ring
GRP cover
FRAMESET
Gravel frameset include: main frame, front boom, front fork,
handlebar, stem, headset, sport chain management parts,
stainless steel screw set, thru-axles
Gravel frameset weight 4.3 Kg (before cut)
Maximum rider weight 105 Kg
Warranty on frameset 2 years
