Superlight Carbon Fiber
Iconic design frameset with integrated cable routing,
Aerodynamic Oversized
Front Boom
Adjustable lenght, internal cable routing, flat front end for
safety, eccentric aerodynamic carbon fin with front
derailleur mount and integrated cable stop.
Super Stiff Frame-Boom
Coupling
The coupling between the telescopic boom and the frame
– made with 4 or 6 screws positioned on the side walls
– is extremely simple and effective. There is no possibility of
unintentional movement and there are no noises under stress.
Adjustable
Carbon Fiber Stem
Internal cable routing, integrated collar with custom made
flat-based screws and aerodynamic carbon stem cover.
Integrated Carbon
Fiber Handlebar
44 cm width for safe and precise handling and minimum
frontal area.
22.2 mm diameter, ready for bar-end shifters, twister
shifters or trigger shifters.
20° angle for relaxed wrists position.
PressFit
Bottom Bracket
86.5 mm wide shell for an
extremely rigid connection
between the cranks and the
frame.
MAIN FRAME
Carbon fiber main frame with internal cable routing
Titanium front and rear seatpost plates with millimeter-precision position adjustment
142 mm rear thru-axle with replaceable rear derailleur hanger
Flat mount disc brake clamp for 140 or 160 mm rear rotor
Rear tire clearance up to 40 mm (700C rear wheel)
Standard finish: glossy 3K carbon
FRONT FORK
Carbon fiber front fork with 100% internal cable routing
1 1/8” – 1 1/2” steerer tube
100 x 12 mm Thru-axle
Flat Mount disc brake clamp
Front tire clearance up to 32 mm (700C front wheel)
Standard finish: matte UD carbon
AERO STEM
Carbon fiber stem with internal cable routing
Carbon top cover + Carbon aero top cover
Finish: glossy 3K carbon
SEAT
Carbon fiber
Adjustable seat height and angle with 4 spacers
Seat-pad available as option
Adjustable neck rest available as option
Finish: glossy 3K carbon
FRONT BOOM
Carbon fiber boom with internal cable routing
Adjustable length (max 578 mm) with cutting mask
PressFit Road BB shell
Frame-Boom pairing with 6-4 screws
Standard finish: glossy 3K carbon
HANDLEBAR
Carbon fiber handlebar with internal cable routing
Adjustable length 300 mm
Width 440 mm
Angle 20°
Diameter 22.2 mm ready for bar-end shifter
Finish: glossy 3K carbon
HEADSET
Token A-Box internal cable routing headset
1 1/2″ steel sealed bearings
Composite compression ring
GRP cover
FRAMESET
Racing frameset include: main frame, front boom, front fork,
handlebar, stem, headset, elite chain management parts,
titanium screw set, thru-axles
Racing frameset weight 4.1 Kg (before cut)
Maximum rider weight 105 Kg
Warranty on frameset 2 years
